How to set up PhpStorm to develop Tiki

PhpStorm

PhpStorm is JetBrains’ integrated development environment for PHP, based on IntelliJ IDEA. As of 2017, PhpStorm is considered the best commercial PHP IDE. JetBrains offers PhpStorm for free for Tiki development.

1. Comparison with alternatives

1.1. Interesting features

In no particular order (yet) by Jonny Bradley

  1. Navigate -> File... (and Class... and Symbol...)
    Especially the way you can type the initials of the words in the filename
    e.g. “t a t o o” gets you tiki-admin_toolbars (the php, tpl and js files if you want)
  2. Edit -> Copy Reference
    Except the way it includes the leading slash... must looks for a pref for that!
  3. Image
    makes me smile, but seriously, the debugger knows what’s going on to a far deeper level than any other PHP IDE i’ve tried
  4. Code -> Refactor as... (variable, method etc)
    Common on Java IDE, but not seen it on PHP
  5. Code -> Comment/Un-comment
    Sounds trivial but it’s the first thing i’ve found that does it correctly in all languages, not just PHP and JS, but Smarty, HTML and CSS too
  6. View -> Compare with clipboard (you can merge changes form the clip board into an open file)
  7. CSS colour indicators
  8. Column select
  9. Tools -> Deployments -> Sync and Diff with Deployment
  10. Code completion on SQL files (fills in tables and column names from your database - thanks Luci ;)
  11. Branch merging - as you would expect, far more civilised (and quick) than any other IDE i’ve tried, and so much more controllable (for me) than using a shell
  12. Shelve changes which reverts your current changes and keeps them in a safe(ish) place until you want them back again
  13. Live templates: create your own idiosyncratic code snippets and insert them by typing an abbreviated name followed by TAB
  14. You can get a free version for use on your Tiki work (see details below)

1.2. Disadvantages compared to Eclipse PDT

  1. The SFTP plugin (Remote Host) is in development. Specifically, as of version 0.1 (PhpStorm 7.1.5), at least on Windows, direct drag-and-drop from/to Windows Explorer is not supported, unlike Eclipse’s Remote System Explorer.

2. Setting it up

 In progress

This section is incomplete and likely outdated.

2.1. Installation

2.1.1. For Tiki work only

If you are a regular contributor to the TikiWiki project, then you may be eligible for a free license to PhpStorm.

  • Contact Nelson (nkoth on IRC) and ask him for the user name and license key.
  • Once you receive the mail, log in to Jetbrains.
  • Download PhpStorm from https://account.jetbrains.com/licenses
  • Start PhpStorm
  • With PhpStorm 2017, you will get prompted on the first launch and can just enter your JetBrains account credentials. If not, keep reading this section...
  • Help > Register
  • Enter the user name and license key exactly as in the email

 Don't enter the key as a single line!

The license key you will have received, may be on several lines.

You must enter it exactly like that, without trying to “unwrap” the key into a single line.

2.1.2. Without a free license

Get PhpStorm from http://www.jetbrains.com/phpstorm/

2.2. Import Tiki Code Style Settings

Download this XML file for PhpStorm 2017, or another file from here for previous versions.
Go to File -> Settings... -> Editor -> Code Style and in the drop-down menu next to the Scheme drop down at the top, select Import Scheme ->Intellij IDEA code style XML.

2.3. Debugger (side of the HTTP server)

Choose a PHP debugger, either Xdebug or Zend Debugger, install and configure it on the HTTP server’s side.

To install Xdebug for PHP 5 on Debian, the following command may be used:

sudo apt-get install php5-xdebug

To install Xdebug under Mac 10.9 Maverick using MacPorts (couldn’t manage to install phpunit) Bernard Sfez / Tiki Specialist :

sudo port install php5-xdebug


To configure Xdebug on the HTTP server’s side, the following settings could be used as a reference:

php.ini
[xdebug]
; Remote settings
xdebug.remote_enable = On
xdebug.remote_cookie_expire_time = 100000 ; 1 day

;xdebug.collect_params = 2

2.3.1. Remote Debugging

Some useful info on setting up xdebug and phpstorm to do remote debugging can be found here: https://confluence.jetbrains.com/display/PhpStorm/Remote+debugging+in+PhpStorm+via+SSH+tunnel, mainly the part about the ssh port 9000 tunnel - that’s the bit that was missing for me Jonny Bradley

2.4. Configuring the PHP interpreter & path

 Skip

This section is outdated. You should probably skip it. 2017-06-26


PhpStorm expects to find the Php interpreter in a particular location (ex: on my mac, it’s /usr/bin/php). But it could be that you are using an interpreter that is in a different location.

Here is how you can do that. The particulars of the steps seem to depend on the version of PhpStorm you use. Below are the steps as described originally by Jonny, and those for PhpStorm 6.0 (written by Alain)

# For PhpStorm 6.0

2.4.1.1. PHP Interpreter

  • Preferences > PHP
  • Click on ... to the right of Interpreter.
  • Browser to the location of the php interpreter (ex: /opt/local/bin)
  • Click on the + sign at the top left, then Specify other
  • For Name, enter a freetext name for that version of the interpreter (you could just set it to the full path)
  • For PHP home, enter the path of the directory that contains the php executable (ex: /opt/local/bin). Do not include php at the end of the path (it has to be a directory, not the path to the executable itself).
  • OK

2.4.1.2. Include path

  • Preferences > PHP
  • Choose the interpreter for which you want to set the path, by clicking on the ... to the right of Interpreter
  • Click on the + sign at the bottom right of the PHP window
  • NOT SURE ABOUT THE REST

# Original instructions by Jonny

File → Settings → PHP (open)

2.4.1.1. PHP Interpreter

Interpreter > Add

Enter the following:
Name: “php on ubuntu” (free text)
PHP home: /usr/bin/
Debugger: Xdebug

→ See appear the PHP version (here PHP version 5.3.... )

2.4.1.2. Include path

  • Click at the plus sign
  • add path to application source (real place without links)

2.5. Server

  • Server
    • Name: localhost
    • Host: localhost
    • Port: 80
    • Debugger: Xdebug
    • (X) Use path mappings (select if the server is remote or symlinks are used)



2.6. Add a PHP Web Application


Open Run -> Edit configurations...
Click on the plus (“+”) sign at the top and select “PHP Web Application”.
Adjust the Name and Start URL fields and select OK.


2.7. Create project(s)

The code edited needs to be in a PhpStorm project. If you are working on several Tiki versions, it is best to create one project per version.

PhpStorm allows to use a single window for all projects or one window per project. Most Tiki developers seem to choose the latter option.

3. Tips

3.1. Updating a checkout

To update a checkout, do VCS -> Update project....
If you have several projects, select the one to update.

Turn on Autoscroll from source option, so that the project browser repositions itself automatically to the page you are currently have in the editors. That way, if you want to do an operation on the file you are editing (ex: delete, rename), or see other files in the viscinity, you can just go from the editor to the project browser.

To set this option on:

  • Click on the project
  • Click on the gear icon (top right of the project browser)
  • Check Autoscroll from source


Make use of the various navigation and search shortcuts. One really powerful thing about those is that you can search for things by specifying parts of its name, that might not be consecutve. So for example, searching for a file with “tiki permissions” will find “tiki-debug-permissions.tpl”.

Below are some of the more useful search and navigation shortcuts:

  • Command+Shift+O: search for a file.
  • Ctrl+Shift+F: Search all files in the project
  • Command+O: Search for a class.
  • Ctrl+Command+O: Search for a symbol (class, method, variable, etc...)

3.3. How to merge

Useful tip provided by jonnyb in the devel list (27/02/15)

Seems that the way i do merging of single commits in phpStorm isn’t in their documentation, i think i just worked it out several versions ago (don’t like manuals mostly

So here’s what i do... let’s say i want to merge a commit from trunk into 14.x...

First thing to do is configure the branches in your project (you need that also to do “Compare with branch...” which is really handy too.

https://www.jetbrains.com/phpstorm/help/configure-subversion-branches.html

It should work out where trunk is, and last time i did it it added branches, mods, third_party etc as branch locations, you can remove everything apart from branches from there (the lower box).

To do a merge, go back to the Changes panel - Working Copy info pane where the config branches link was and just under it is “Merge from...” - click that and the little drop down branch menu appears, click “trunk” (in this case) and you get the “Select Merge Variant” dialog, with “Quick Manual Select” button, should be obvious from there (?)

The other two options (merge all, only any use when merging an experimental branch back into trunk, but i’ve never used it, looked too scary!) and Select with pre-filter, which takes ages and ages on tiki, probably due to our extensive history (and svn being a bit rubbish at this).

Hope that helps, odd that it’s not on their documentation (afaics)

jonny

P.S. Compare with branch instructions are here https://www.jetbrains.com/phpstorm/help/comparing-with-branch.html

4. Troubleshooting

“Could not save project” error

If you get this error, it probably means that the permissions on your Tiki files are wrong. Typicall, when you run setup.sh, all the files in Tiki end up being owned by _www with _www as the group (unless you specify other choices). But on most platforms (at least on Mac), PhpStorm runs as your own regular user, which is not part of group _www.

Here is how to fix this issue on Mac. Details for other platforms may vary.

# First, add your user name to group _www
sudo dseditgroup -o edit -a yourusername -t user _www

# Next, rerun setup.sh, but this time, specify
# yourusername as the user, but leave _www as
# the group
sudo sh setup.sh

# Then make sure certain directories are writeable
# by the _www group.
sudo chmod -R g+w db dump img/wiki img/wiki_up img/trackers modules/cache templates_c templates styles whelp

‘Cannot find PHPUnit in include path’ error

When attempting to run project ‘9.x’ on ‘LocalApache’ server, I see these messages:

Cannot find PHPUnit in include path (.:/usr/share/php:/usr/share/pear)
Unable to attach test reporter to test framework or test framework quit unexpectedly


Once phpunit is installed (& phpstorm restarted), the error message dissapears.

‘Debug server doesn’t exist’ error

When attempting to go to “Run > Debug ‘9.x on LocalApache’”, I see this message at the bottom:

Error running 9.x on LocalApache:
Debug server doesn’t exist. Check ‘Remote’ tab in run configuration editor.


Ok, after I added “localhost” as Debug Server, and run again “Run > Debug ‘9.x on LocalApache’”, I did get these messages:

Testing started at 18:35 ...
Executing tests
Http request failed: HTTP/1.0 500 Internal Server ErrorE_WARNING: require_once(Zend/Cache/Backend/ExtendedInterface.php): failed to open stream: No such file or directory

  1. 0 /var/www/9.x/lib/core/Zend/Cache/Backend/Test.php(27): require_once()
  2. 1 /usr/share/php/PHPUnit/Util/Fileloader.php(95): include_once()
  3. 2 /usr/share/php/PHPUnit/Util/Fileloader.php(79): load()
  4. 3 /var/www/9.x/_intellij_phpunit_launcher.php(527): checkAndLoad()
  5. 4 /var/www/9.x/_intellij_phpunit_launcher.php(821): collectTestsFromFile()
  6. 5 /var/www/9.x/_intellij_phpunit_launcher.php(929): main()

E_COMPILE_ERROR: require_once(): Failed opening required ‘Zend/Cache/Backend/ExtendedInterface.php’ (include_path=’.:/usr/share/php:/usr/share/pear’)

  1. 0 /var/www/9.x/lib/core/Zend/Cache/Backend/Test.php(27)

Can’t commit a change

Sometimes, nothing happens when you click on the Commit button.

When that happens, make sure you uncheckall the boxes in the Subversion and before commit section have to be unchecked.

PhpStorm Svn Commit Options

‘Connection with ‘xdebug’ was not established’ error

You typically get this error when running the debugger PHP Script run configuration.

The error usually means that the PHP interpreter you are using does not have the xdebug extension installed.

To find out which interpreter you are using

  • Preferences > PHP
  • Click on ... to the right of the Interpreter field
  • The path of the interpreter is in the PHP Home field.


To see if xdebug is installed for that interpreter:

pathtoyourinterpreter/php -i | grep xdebug

If the phpinfo doesn’t contain any line with xdebug, it means it’s not installed.

To install xdebug for use with PhpStorm, see the Configuring the Debugger section above.

PhpStorm becomes sluggish

If you notice that PhpStorm occasionally gets in a rut and becomes very slow in responding to your actions, it probably means that you haven’t allocated enough heap memory to it.

The way to fix it is to add the heap size in file idea.vmoptions. On the mac, this file is located under ~/Library/Preferences/WebIde60/.

For example, here is Alain’s idea.vmoptions file:

-Xms128m
-Xmx2048m
-XX:MaxPermSize=350m
-XX:ReservedCodeCacheSize=96m
-XX:+UseCodeCacheFlushing
-XX:+UseCompressedOops

Can’t use svn from command line

Although the graphical svn UI in PhpStorm is pretty good, there may be time when you want to use the command line SVN.

If you do that, it could be that the command line SVN will complain that the current directory is in the wrong SVN format.

This is usually due to the fact that PhpStorm uses its own version of SVN (which is embedded as a java library), and that it uses a SVN data format that is more recent that the command line SVN you are using. For example, maybe your command line SVN uses the 1.6 format, while the PhpStorm svn uses 1.7.

There are two ways to deal with this

  • Upgrade your command line SVN so it can deal with the data format version used by PhpStorm.
  • Redo the checkout, but ask PhpStorm to store the data in the format that your command line uses.


As of this writing (Oct 29, 2013), the easiest option for Mac users seems to be to redo the checkout, because macport doesn’t seem to have version 1.7 of the command line SVN (which is what PhpStorm uses by default).

5. Useful links

Free video tutorial to help you setting (xdebug) and customising PhpStorm: https://laracasts.com/series/how-to-be-awesome-in-phpstorm/
